ASIGA PRO 4K

$38,950 ex GST
$34,635 ext GST

The PRO 4K utilizes the latest DLP imaging technology to achieve the largest print envelope in our range. Ideal for Dental, Audiology and Jewelery industries.

DOWNLOAD PRO 4K BROCHURE

Industry Proven Performance

Precision, reliability and speed for the most demanding production applications.

The Latest DLP Imaging Technology

Coupled with custom engineered optics for precision pixel placement.

Super Fast Print Mode Available

Volume production in minimal time.

Proprietary Layering Processes

Repeatable precision with Asiga's proven Process Monitoring Technologies - SPS, Internal Radiometer, precise material curing.

Beautifully Engineered

User defined interface and operability for ease of use..

SPS™ Smart-Positioning-System Technology

Asiga's unique SPS™ process guarantees every layer is formed accurately. Accurate layer formation is the key to achieving consistently accurate results in any production environment.

Open Material System

Select from a range of Asiga materials with the added benefit of using any material from any manufacturer.

View Materials

Seamless Integration

Simple touch screen user interface and multiple connection options for seamless integration into your digital workflow.

Technical Specifications

Product specification PRO 4K65 PRO 4K80
Build Volume X, Y, Z 176 × 99 × 200mm
6.94 × 3.9 × 7.87 inches
217 × 122 × 200mm
8.54 × 4.8 × 7.87 inches
Pixel Resolution 65µm 80µm
Technology DLP DLP
LED Wavelength 385nm (high power UV LED) or 405nm
Material Compatibility Asiga materials, 100% Open Material System — use any suitable third party material
Software Asiga Composer software. Lifetime updates included
File Inputs STL, SLC, PLY, STM (Asiga Stomp file format)
Network Compatibility Wifi, Wireless Direct, Ethernet
Power Requirements 100 to 240 VAC, 50/60 Hz, ≤500 Watts (at 100 V ≤5 Amps, at 240 V ≤2.1 Amps)
System Sizing 465 × 420 × 1370mm / 75 kg    18.3 × 16.5 × 53.9 inches / 165 lb
Packed Sizing 900 × 700 × 1540mm / 205 kg    35.4 × 27.6 × 60.6 inches / 452 lb
Warranty 12 months manufacturer's warranty
Technical Support Unlimited lifetime technical support included
Bundle Includes 3D printer, Composer software, 1 kg Asiga material, 1L build tray, Asiga Flash post-curing chamber, calibration toolkit
HP 3D Process Control

Composer

Composer is the software interface to all our 3D Printers. Powerful, intuitive and free.

HP 3D Center

Asiga Flash

A compact post curing device for curing parts after printing.

HP SmartStream 3D Build Manager

Calibration Toolkit

All the tools you need to calibrate your Asiga 3D printer.

HP SmartStream 3D Build Manager

Material Pack

1L Asiga material pack included. Material pack consists of 1L material bottle and 1L build tray.

Digital dentistry hero image

Industrial Manufacturing

Tough, functional and high temperature materials suitable for end-use parts and injection mold tooling inserts. Compatible with leading additive manufacturing materials including Henkel Adhesives.

Digital dentistry hero image

Digital Dentistry

From restorative dentistry to orthodentic devices. Produce surgical drill guides, removable die models, ortho models, custom impression trays, splints, partial frameworks, crown & bridge, inlays / onlays, gingiva and a range of dental appliances all on Asiga 3D printers.

Jewelry Manufacturing hero image

Jewelry Manufacturing

Reduce time to market further by adding an Asiga 3D printer to you bench. Extraordinary surface smoothness and impeccable detail definition, unlike anything you've seen before.

Digital Audiology hero image

Digital Audiology

Precision, speed and productivity make Asiga 3D printers the ideal choice for a digital audiology workflow.

∗ Specifications subject to change without notice.
∗∗ Material dependent.
